BB-3 running within Sid Meier's Civilization: Beyond Earth.

Animated, in-game construction of the three-state Busy Beaver (BB-3) as described in the paper "Turing Completeness and Sid Meier's Civilization".
All products, company names, brand names, trademarks, and images are properties of their respective owners. The images are used here under Fair Use for the educational purpose of illustrating mathematical theorems.

(From the paper): The Busy Beaver game is a game in theoretical computer science. It challenges the player (a Turing machine or a human player) to find a halting Turing machine with a specified number of states \(n\), such that it writes the most number of \(1\)s on the tape out of all possible \(n\)-state turing machines. The winner is referred to as the \(n^{\text{th}}\) Busy Beaver, or BB\(-n\).

In the paper we show that it is possible to build a universal Turing machine (UTM) within Sid Meier's Civilization: Beyond Earth (Civ:BE), as well as other games.
Below we display the execution of BB\(-3\) with the \((10, 3)\)-UTM built in Civ:BE. Refer to the paper for a translation of the Turing machine for BB-3 into the "language" of the Civ:BE \((10, 3)\)-UTM, and this page for a description of the components of the UTM.

The machine executes \(11\) instructions \(t_1, \dots, t_{11}\) before halting. The image below displays sample states (clockwise from the top-left): \(t_1 = q_00;1Rq_1\), \(t_2 = q_10;1Lq_0\), \(t_{10} = q_01;1Lq_2\), and \(t_{11} = q_21;HALT\), while the gif at the bottom of this page shows the entire execution of BB-3 in the UTM.
